Connected street lights

individual light control

iLuminate

Street lighting is an essential service and reporting and maintenance delays compromises safety of citizens. Self sufficient smart light, that reports it's own failure without dependance on any external service is the need of the hour. These lights also help save tonnes of carbon emissions by dimming the lights in non peak ours, or based on inputs from sensors.

The technologies

LORAWAN, LoRa is a low-power wide-area network protocol developed by Semtech. It is based on spread spectrum modulation techniques derived from chirp spread spectrum technology. It is apt for street lighting control.

This solution comes with a highly secure Network server and UI server

M2M, as the penetration of telecom network increases it only makes sense to use it for all possible networking. With the success of iFeeder, Citilight has launched the most extensive product range of individual lights controllers -

2G M2M

NBIOT M2M

HYBRID-M2M

The solution

Citilight individual lighting solutions are compliant to most tender specifications. They primarily include the following parts.

LED Street light (with dimmable driver)

A standard street light with a 0-10V or DALI dimmable driver to ensure dimming feature works seamlessly for the project duration, we recommend using Citilight approved drivers

iLuminate ILC Module

This module controls the lights, measures energy consumption (1% accuracy), follows astronomical schedule, communicates with gateway or cloud server directly and executed sensor based actions, for example, light turns on once light level drops. One iLuminate node can control upto 4 lights together

Gateway

The iLuminate modules communicate in a start topology with the gateway. The gateway is the network co-ordinator and completes the connection of the light with the cloud server. A gateway can control upto 5000 devices

Physical or Cloud server

The network of street lights sends data to the Citilight AWS cloud servers. Smart light server applications are all available for on premise hosting as well. Click here for more details

Smart lighting myths

Q. Smart Street Lighting Projects are out of budget?

AWith stabilisation of technology and reaching of economies of scale, smart street lighting solutions have proven extremely beneficial for cities and the overall cost of solution has come down considerably.

Q. If my feeder automation solution and light automation solution will not talk to each other i can not have a unified solution for my city?

A. Lets answer this question in two parts

1. If you are using a feeder solution other than iFeeder (by Citilight) in that case we use industry proven API to make a single dashboard of both the feeders and individual light controller

2. iFeeder and iLuminate together form a unified solution (single login) for the user to access all the data in one dashboard, which includes reports, analytics, ticketing software, control, map view, user management, inventory management, etc.

Click here for more details
